| Spesifikasi : | |||
| ● | Monitor | : | Size: 165 x 127 x 38 mm |
| TFT-Display: 5.6“ | |||
| Video-Out: RCA | |||
| Weight: 400 g | |||
| Current Supply: 2 x batteries 12 V/1,2 Ah | |||
| battery life time: 1 hour per battery | |||
| ● | Miniature camera head | : | Sensor type: 1/3“ COLOUR CCD |
| Pixel: 768 x 512 | |||
| Sensitivity: 0.5 Lux | |||
| Field of view: 120° | |||
| Light source: 12 white LEDs | |||
| Protection: watertight according to IP 68 | |||
| Size: 26 mm x 38 mm Ø | |||
| Weight: 60 g | |||
| Work temperature: -10 - 50 °C, RH 95% MAX | |||
| Storage temperature: -20 - 60 °C, RH 95% MAX | |||
| ● | Metric marked rod | : | Length: 20 m |
| Diameter: 6 mm | |||
| ● | Heavy duty carrying case | : | Size: 51 x 43 x 17 cm |
| Weight: 7 kg | |||
| ● | Locator (optional) | : | Frequency (transmitter): 32.768 kHz |
| Frequency (Modulation): ca. 32 Hz | |||
| Current Supply: by VIS 2xx | |||
| Work temperature: 0…40 °C | |||
| Storage termperature: -10…40 °C | |||
| Weight: 55 g | |||
| Size: 30 mm x 90 mm Ø | |||
| Protection: IP 68 | |||
| ● | Receiver | : | Display: fast analog indicator |
| ● | Outputimpedance | : | Head set: typ. 8 Ohm |
| Current supply: 9 V battery | |||
| Work Temperature: 0 up to 40 °C | |||
| Storage Temperature: -20 °C up to 50 °C | |||
| Weight: 140 g | |||
| Size: 130 x 60 x 30 mm | |||
| • | Manual | : | Bahasa Inggris dan Indonesia |
| • | Kartu Garansi | ||
